| Spindle taper | 7:24 IS0 50(Horizontal/Vertical) |
| Distance spindle to column surface | 1700X400 mm |
| Worktable swivel angle | ±45° |
| Number | 4 |
| T-slots of table width | 18mm |
| Distance | 100mm |
| Spindle speeds range | 12steps 50-1520r.p.m(Vertical)12steps 60-1850r.p.m(Horizontal) |
| X-Longitudinal | 1300 mm |
| Y-Table travel Cross | 420 mm |
| Z-Vertical | 600 mm |
| X.Y. axes feeding | 25-800 mm/min Rapid feeding 800 mm/min |
| Z axes feeding | 8-267 mm/min Rapid feeding 267 mm/min |
| main horizontal spindle | 0-440 mm |
| milling head horizontal(low position) | 150-590 mm |
| milling head horizontal(side position) | 340-780 mm |
| milling head horizontal(hish position) | 530-970 mm |
| Distance from spindle nose to worktable | 50-650 mm(Vertical) |
| Distance from Vertical spindle cente, to guideway surface | 0-1000 mm(Vertical maillingspindle head) |
| horizontal swivel angle of milling head | 360° |
| Vertical swivel angle of milling head | 360° |
| Main motor | Vertical Milling 7.5KW(V) Horizontal Milling 5.5KW(H) |
| Feeding motor | 2.36 KW 15N.M |
| Coolant pump motor | 9OW |
| Coolant pump flux | 25Litres/minute |
| Overall dimensions | 2300X2300X2270 mm |
| G.W | about 3600 kg |
